I. Summary of HG114 API Tube mill ine

GOODBUSINESS16@GMAIL.COM

HG114 ERW pipe making machine is used to manufacture weld steel pipe of Φ50mm-Φ114mm with 1.5mm-5.4mm of wall thickness, can produce profiled pipe also within the limit of processing round pipe. After we absorbed advanced pipe making technology from both abroad and domestic, our innovative designed production line and each single unit of the production line is not only economical but also practical.

II. Basic conditions:

(I) Steel Pipe Specification

(1) Round Pipe: Φ50-Φ114mm

Thickness: 1.5-5.4mm

(2) Square and Rectangle Pipe: 40X40-90X90mm

Thickness: 1.5-4.0mm

(4) Length of Steel Pipe: 6-12m

(II) Strip steel

Low carbon steel and low alloy steel: δb≤500Mpa

δs≤235Mpa

III. The technical flow of the production line

Scroll up→Uncoil→Flattening→Cutting head, tail→Strip Steel head-tail butt welding→Looping storage→Confectioning→High-frequency induction welding

→Removing external burr→Removing internal burr→Cooling→Forming →Cutting→Checking & Collecting→Binding→Weighing→Marking→Accessing Warehouse

Remark:

To protect confidential information, Here only show basic parameters. Detailed parameter will be known in the quotation list or negotiate with customer.

Hebei Younik Machinery Co.Ltd,founded in 2010, is a leading and famous manufacturer of specialized in ERW/HF tube mill，coil slitting line， and all kinds of roll former, also tube related machinery. We have earned an excellent reputation in both domestic & international market in the past two decades.

We always believe that "Customer's business is our Business." We provide a 24 hours nonstop after service to all customers in the world. You are not only buy the machine from us, you buy TUBE technology and tooling know-how as well.

Applications:
Our tube machinery is designed to process tubes that are used widely in aircraft, transportation equipment (including tankers), buildings (including exterior wall cladding and escalators), tunnel engineering, furniture, refrigerating and air-conditioning products, sports equipment, entertainment facilities, power plants, petroleum-related equipment, water piping, sewage treatment facilities, landscaping, bridges, and autos, motorcycles and bicycles, as well as in the chemical engineering, iron processing, and fertilizer-making industries.
